Automatic Weighing Filling Machine KWS688-1/688-2

Short Description:

We provide down filling machines of various models and purposes, which are widely used in garment, home textile and toy processing industries. This equipment can be filled with 30/40/50/60/70/80/90 down, feather silk, ball yarn and polyester staple fiber. The machine adopts fully automatic computer intelligent control, accurate and stable, one machine with multiple functions. Support remote management and system upgrade, support multiple languages.

Send email to us

Product Detail

Product Tags

Features

Built-in weighing system, each filling nozzle is equipped with two to eight scales for cycle weighing filling, and up to four filling nozzles can be used at the same time. The filling accuracy is high, the speed is fast, and the error is less than 0.01g. All electrical components are of international famous brands, and the accessories standards conform to the "International Electrotechnical Standards" and the safety regulations of Australia, the European Union and North America.
The components are highly standardized and generalized, and the maintenance is simple and convenient.
The sheet metal is processed by advanced equipment such as laser cutting and CNC bending. Surface treatment adopts electrostatic spraying process, beautiful and generous, durable.

Automatic Weighing Filling Machine KWS688_002

Automatic Weighing Filling Machine KWS688_001

Automatic Weighing Filling Machine KWS688_003

Specifications

Automatic Weighing Filling Machine KWS688-1
Scope of use	Down jackets, cotton clothes, pillow cores, quilts, medical thermal insulation jackets, outdoor sleeping bags
Refillable material	Down, goose,feathers, polyester, fiber balls, cotton, crushed sponges, and mixtures of the above
Motor size/1 set	17009002230mm
Weighing box size/1set	12006001000mm
Weight	550 KG
Voltage	220V 50HZ
Power	2KW
Cotton box capacity	12-25KG
Pressure	0.6-0.8Mpa Gas supply source need ready compress by yourself ≥11kw
Productivity	1000g/min
Filling port	1
Filling range	0.2-95g
Accuracy class	≤0.1g
Process requirements	Quilting after filling,Suitable for filling larger cutting pieces
Scales by filling port	2
Automatic circulation system	High-speed automatic feeding
PLC system	1 PLC touch screen can be used independently, supports multiple languages, and can be upgraded remotely

Automatic Weighing Filling Machine KWS688-2
Scope of use	Down jackets, cotton clothes, pillow cores, quilts, medical thermal insulation jackets, outdoor sleeping bags
Refillable material	Down, goose,feathers, polyester, fiber balls, cotton, crushed sponges, and mixtures of the above
Motor size/1 set	17009002230mm
Weighing box size/2sets	12006001000mm
Weight	640 KG
Voltage	220V 50HZ
Power	2.2KW
Cotton box capacity	15-25KG
Pressure	0.6-0.8Mpa Gas supply source need ready compress by yourself ≥11kw
Productivity	2000g/min
Filling port	2
Filling range	0.2-95g
Accuracy class	≤0.1g
Process requirements	Quilting after filling,Suitable for filling larger cutting pieces
Scales by filling port	4
Automatic circulation system	High-speed automatic feeding
PLC system	2 PLC touch screen can be used independently, supports multiple languages, and can be upgraded remotely

Automatic Weighing Filling Machine KWS688_005

Automatic Weighing Filling Machine KWS688_004

Automatic Weighing Filling Machine KWS688_006

Applications

The automatic weighing and high-efficiency down filling machine is suitable for producing various styles of down jackets and down products. Widely used in warm winter clothes, down jackets, down pants, lightweight down jackets, goose down jackets, padded clothes, sleeping bags, pillows, cushions, duvets and other warm products.
